Removal and Replacement Procedures
Maintenance and Service Guide 5–3
Section Description
# of Screws
Removed
5.5 Mini PCI communications board 1
5.6 MultiBay device 0
5.7 Bluetooth wireless communications
board
3
5.8 Keyboard 2
5.9 Modem board 2
5.10 Memory expansion board 0
5.11 Switch cover 2
5.12 Keyboard plate 0
5.13 Fan assembly 5
5.14 Heat sink 4
5.15 Processor 0
5.16 Display assembly 4
5.17 Top cover 16
5.18 RTC battery 0
5.19 LED board 0
5.20 Bottom board 2
5.21 System board 5 screws,
2 standoffs
Disassembly Sequence Chart
(Continued)
To Next Page
