HP Compaq nc6000

C–2 Maintenance and Service Guide
Screw Listing
Table C-1
Torx T5M3.0×4.0 Screw
Color Qty. Length Thread
Head
Width
Silver 2 4.0 mm 3.0 mm 5.0 mm
Where used:
1 Two screws that secure the hard drive frame to the hard drive
(documented in Section 5.3)
mm
Table C-2
Phillips PM3.0×3.5 Screw
Color Qty. Length Thread
Head
Width
Silver 2 3.5 mm 3.0 mm 5.0 mm
Where used:
2 Two screws that secure the hard drive frame to the hard drive
(documented in Section 5.3)
mm
Table C-3
Hex M2.0×10.0 Alignment Pin
Color Qty. Length Thread
Head
Width
Silver 2 10.0 mm 2.0 mm 4.0 mm
Where used:
3 Two alignment pins that secure the hard drive frame and connector to the
hard drive (documented in Section 5.3)
mm
