HP Compaq nc6000

C–8 Maintenance and Service Guide
Screw Listing
Torx T8M2.5×5.0 Screw Locations
Table C-5
Torx T8M2.5×5.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 13 5.0 mm 2.5 mm 4.0 mm
Where used:
1 Two screws that secure the bottom board to the notebook
(documented in Section 5.20)
2 Five screws that secure the system board to the notebook
(documented in Section 5.21)
mm
