HP Compaq nc6000

C–18 Maintenance and Service Guide
Screw Listing
Phillips M2.0×3.5 Screw Locations
Table C-12
Phillips M2.0×3.5 Screw
Color Qty. Length Thread
Head
Width
Black 5 3.5 mm 2.5 mm 4.0 mm
Where used:
Five screws that secure the top cover to the notebook (three in the MultiBay,
two in the hard drive bay; documented in Section 5.17)
mm
