1–14 Maintenance and Service Guide
Product Description
Table 1-3
Front and Left-Side Components
Item Component Function
1 Audio line-out jack Produces system sound when connected to
optional powered stereo speakers,
headphones, headset, or television audio.
2 Microphone jack Connects an optional monaural
microphone.
3 Hard drive bay Holds the primary hard drive.
4 MultiBay device slot Holds a MultiBay device.
5 Infrared port Provides wireless communication between
the notebook and an optional
IrDA-compliant device.
6 Mute button On: Mutes the system volume. A light
comes on when the button is pushed in and
the sound is muted.
7 Volume control
buttons
Increase and decrease system volume.
Press the volume up button to increase
sound. Press the volume down button to
decrease sound.
8 Stereo speakers (2) Produce stereo sound.
9 Display release latch Opens the notebook.
