6–38 Maintenance and Service Guide
Removal and Replacement Procedures
8. Swing the display assembly into a partially closed position.
9. Position the computer with the rear panel toward you.
Ä
CAUTION: Support the display assembly when removing the following
screws. Failure to support the display assembly can result in damage to
the display assembly and other computer components.
10. Remove the 4 Torx8 T8M2.0×9.0 screws 1 that secure the
display assembly to the computer.
11. Lift the display assembly 2 straight up and remove it.
Removing the Display Assembly
Reverse the above procedure to install the display assembly.
