Removal and Replacement Procedures
Maintenance and Service Guide 5–7
5.4 Hard Drive
1. Prepare the computer for disassembly (refer to Section 5.3).
2. Position the computer with the front toward you.
3. Loosen the two Phillips PM2.0×4.0 screws 1 that secure the
hard drive cover to the computer.
4. Lift the right side of the hard drive cover 2 and swing it up
and to the left.
5. Remove the hard drive cover.
✎
The hard drive cover is included in the Plastics Kit, spare part
number 413704-001.
Hard Drive Spare Part Number Information
7200-rpm,
60-GB
413854-001 5400-rpm, 100-GB
5400-rpm, 80-GB
5400-rpm, 60-GB
5400-rpm, 40-GB
413853-001
413852-001
413851-001
413850-001
To Next Page
