5–12 Maintenance and Service Guide
Removal and Replacement Procedures
5.6 Bluetooth Module
1. Prepare the computer for disassembly (refer to Section 5.3).
2. Remove the hard drive (Section 5.4).
3. Slide the Bluetooth module 1 out of the clip in the hard drive
compartment.
4. Disconnect the Bluetooth cable 2 from the module.
Removing the Bluetooth Module
Reverse the above procedure to install a Bluetooth module.
Bluetooth Module Spare Part Number Information
Bluetooth module (includes Bluetooth cable) 398393-001
