Removal and Replacement Procedures
Maintenance and Service Guide 5–43
5.18 Display Assembly
1. Prepare the computer for disassembly (Section 5.3).
2. Remove the memory compartment cover (Section 5.7) and
disconnect the wireless antenna cables from the Mini Card
WLAN module (Section 5.8).
3. Remove the keyboard (Section 5.10).
4. Remove the switch cover (Section 5.17)
Display Assembly Spare Part Number Information
Display assemblies for use with computer models with WWAN (include wireless
antenna transceivers and cables)
15.0-inch, SXGA+WVA, TFT
15.0-inch, XGA, TFT, with BrightView
430967-001
430966-001
Display assemblies for use with computer models without WWAN (include
wireless antenna transceivers and cables)
15.0-inch, SXGA+WVA, TFT
15.0-inch, XGA, TFT, with BrightView
15.0-inch XGA, TFT
14.1-inch XGA, TFT
413679-001
413678-001
413677-001
413676-001
