5–14 Maintenance and Service Guide
Removal and Replacement Procedures
2. Loosen the PM2.0×5.0 screw 1 that secures the memory
module compartment cover to the notebook.
3. Lift the left edge of the cover up and swing it to the right 2.
4. Remove the memory module compartment cover.
✎
The memory module compartment cover is included in the
Miscellaneous Plastics Kit, spare part number 374747-001.
Removing the Memory Module Compartment Cover
To Next Page
