2-2 Hardware Upgrades
Compaq Confidential - Need to Know Required
Writer: Beth Zanca Part Number: 190709-001 File Name: ch2.doc
Last Saved On: 04/12/00 1:02 PM Last Saved By: Lydia Sanchez
Installation Sequence
Follow this sequence of steps to ensure the proper installation of any
optional equipment. Before you begin, observe the following
precautions:
!
WARNING: To reduce the risk of personal injury from hot surfaces,
allow the internal system components to cool before touching them.
!
WARNING: To reduce the risk of electric shock, fire, or damage to
the equipment, do not plug telecommunications/telephone
connectors into the network interface controller (NIC) receptacles.
CAUTION: Static electricity can damage the electronic components
of the workstation or optional equipment. Before beginning these
procedures, ensure that you are discharged of static electricity by
briefly touching a grounded metal object.
1. Turn off the workstation and disconnect the power cord from the
grounded AC outlet and the back of the workstation.
2. Open the workstation by removing its workstation access panel.
See the section, Removing the Workstation Access Panel, in
this chapter for instructions.
3. If you are installing or removing drives in the front bays, see the
section, Removing the Front Bezel, in this chapter for
instructions.
4. Install any optional equipment, such as memory, drives, expansion
boards, a processor, or battery. See the appropriate sections in this
chapter or the appendix for installation instructions.
5. Replace the front bezel and the workstation access panel, if
necessary.
6. Reconnect the power cord to the back of the workstation and plug
the power cord into a grounded AC outlet.
7. Turn on the monitor, workstation, and any devices you installed.
8. Reconfigure the workstation, if necessary.
9. Test the workstation (optional) using the TEST utility.
