Installing a Processor
You can upgrade the workstation to a multiprocessor system. When
you install a second processor, it must be the same speed, cache size,
and type as the existing processor.
!
WARNING: To reduce the risk of personal injury from hot surfaces,
allow the internal system components to cool before touching them.
CAUTION: Installing the processor incorrectly may cause damage
the system board. Have a Compaq authorized reseller or service
provider install the processor. If you plan to install it yourself, read all
of the instructions carefully before you begin.
To install a second processor:
1. Turn off the workstation and disconnect the power cord from the
grounded AC outlet and the back of the workstation.
2. Remove the workstation access panel. Refer to Removing the
Workstation Access Panel in this chapter.
3. Insert the processor 1, then close the two release latches 2.
4. Tighten the middle screw 3.
Installing a second processor
