HP CQ60 Series - Phillips Pm2.5 X11.0 Captive Screw

Screw listing 7–16
Phillips PM2.5x11.0 captive screw
Where used: 4 screws that secure the fan/heat sink to the base enclosure (screws are secured by C-clips) on
computer models equipped with graphics subsystems with discrete memory
Color Quantity Length Thread Head diameter
Silver 4 11.0 mm 2.5 mm 5.0 mm
