Removal and replacement procedures 4–10
Hard drive
The hard drive spare part kit includes a hard drive bracket and hard drive connector. The hard drive bracket and
hard drive connector, as well as the hard drive bracket screws, are also available in the Hard Drive Hardware Kit.
Before removing the hard drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see “Battery” on page 4-7).
Remove the hard drive:
1. Loosen the two Phillips PM2.5×6.0 captive screws 1 that secure the hard drive cover to the computer.
2. Lift the right side of the hard drive cover 2, swing it up and to the left, and remove the cover. The hard drive
cover is included in the Plastics Kit, spare part number 486621-001.
Description Spare part number
120-GB, 5400-rpm 504072-001
160-GB, 5400-rpm 498478-001
200-GB, 5400-rpm 505971-001
250-GB, 5400-rpm 498477-001
320-GB, 5400-rpm 498476-001
Hard Drive Hardware Kit 504059-001
