Illustrated parts catalog 3–9
Display assembly components
Item Description Spare Part Number
(1) Display bezel
For use only with 16-inch HP G60 display bezels (includes microphone) 497097-001
For use only with 16-inch HP G60 display bezels (includes microphone and webcam) 497098-001
For use only with 16-inch silver HP G60 display bezels (includes microphone) 502954-001
For use only with 16-inch silver HP G60 display bezels (includes microphone and webcam) 502955-001
For use only with 15.6-inch HP G60 display bezels (includes microphone) 497101-001
For use only with 15.6-inch HP G60 display bezels (includes microphone and webcam) 497102-001
For use only with 15.6-inch silver HP G60 display bezels (includes microphone) 502956-001
For use only with 15.6-inch silver HP G60 display bezels (includes microphone and webcam) 502957-001
For use only with 16-inch CQ60 display bezels (includes microphone) 497095-001
For use only with 16-inch CQ60 display bezels (includes microphone and webcam) 497096-001
For use only with 15.6-inch CQ60 display bezels (includes microphone) 497099-001
For use only with 15.6-inch CQ60 display bezels (includes microphone and webcam) 497100-001
(2) Display Hinge Kit (includes left and right display hinges) 486558-001
(3) Webcam module (does not include webcam module cable) 488385-001
Webcam Cable Kit (not illustrated) 496842-001
(4) Display inverter 486556-001
(5) Display panel brackets (include left and right brackets)
For use with16-inch display panels 496843-001
For use with15.6-inch display panels 496844-001
(Continued)
