Illustrated parts catalog 3–6
(15) Power connector cable 496835-0001
(16) Optical extension board 506951-001
(17) Bluetooth® module (does not include Bluetooth cable) 483113-001
Bluetooth cable (not illustrated) 496836-001
(18) Base enclosure (includes rubber feet)
For use only with computer models equipped with a built-in modem, Digital Media Slot, and
an HDMI port (includes card reader, not illustrated)
496825-001
For use only with computer models equipped with a built-in modem and Digital Media Slot,
without an HDMI port
492826-001
For use only with computer models equipped with a built-in modem, without Digital Media
Slot and HDMI port
496827-001
For use only with computer models equipped with a built-in modem, HDMI port, without
Digital Media Slot
504740-001
Rubber Feet Kit (not illustrated, includes 6 rubber feet) 486623-001
(19) Battery, 6-cell, 2.20-Ah, 47-Wh 485041-001
(20) Hard drive (includes hard drive bracket and connector)
320-GB, 5400-rpm 504072-001
250-GB, 5400-rpm 498478-001
200-GB, 5400-rpm 505971-001
160-GB, 5400-rpm 498477-001
120-GB, 5400-rpm 498476-001
Hard Drive Hardware Kit (not illustrated, includes connector, bracket, and screws) 504059-001
(21) RTC battery 501587-001
(22) Memory modules
PC2-6400, 667-MHz, DDR2
2-GB 485033-005
1-GB 485032-005
512-MB 485031-005
PC2-5300, 667-MHz, DDR2
2-GB 498475-001
1-GB 498474-001
512-MB 498473-001
(Continued)
Item Description Spare Part Number
