HP CQ60 Series User Manual

Removal and replacement procedures 4–33
6. Remove the four Phillips PM2.0x4.0 screws 1 that secure the TouchPad board to the base enclosure. Then
remove the TouchPad board and bracket 2.
7. Remove the two Phillips PM2.0x4.0 screws 1 that secure the switch actuator to the TouchPad board bracket,
and then remove the actuator 2.
✎
The TouchPad is glued to the top cover and is included with the top cover spare part.
Reverse this procedure to install the TouchPad on/off button board and board bracket.

HP CQ60 Series Specifications

General

Audio	Altec Lansing speakers
RAM	Up to 4GB DDR2
Storage	320GB HDD
Display	15.6" diagonal High-Definition HP BrightView Widescreen Display
Graphics	Integrated Intel Graphics Media Accelerator 4500M
Operating System	Windows Vista
Optical Drive	DVD±RW DL LightScribe
Battery	6-cell Lithium-Ion
Chipset	Intel GL40 Express
Wireless	802.11b/g
Ports	3 x USB 2.0, 1 x HDMI, 1 x VGA, 1 x RJ-45, 1 x Headphone, 1 x Microphone
Card Reader	5-in-1 integrated Digital Media Reader
Webcam	Integrated webcam
Networking	10/100 Ethernet
Weight	2.7 kg (5.95 lbs)
