HP CQ60 Series User Manual

Removal and replacement procedures 4–42
✎
Due to the adhesive quality of the thermal material located between the fan/heat sink assembly and system board
components, you may need to move the fan/heat sink assembly from side to side to detach the assembly.
3. Turn the system board upside down with the fan assembly toward you.
Å
WARNING: To avoid damage to the processor, loosen the fan/heat sink screws in the 1-2-3-4 sequence indicated. Likewise,
tighten the screws in the same sequence when installing the fan/heat sink assembly.
✎
Steps 4 through 5 apply only to computer models equipped with graphics subsystems with UMA memory.
4. Following the 1, 2, 3, 4 sequence stamped into the heat sink, loosen the four Phillips PM2.0x10.0 spring-loaded
captive screws 1 that secure the fan/heat sink assembly.
5. Remove the fan/heat sink assembly 2 by lifting it straight up.
✎
Steps 6 through 7 apply only to computer models equipped with graphics subsystems with discrete memory.
6. Loosen the 4 Phillips PM2.0x11.0 spring-loaded captive screws 1 that secure the fan/heatsink assembly.
7. Remove the fan/heat sink assembly 2 by lifting it straight up.

HP CQ60 Series Specifications

General

Audio	Altec Lansing speakers
RAM	Up to 4GB DDR2
Storage	320GB HDD
Display	15.6" diagonal High-Definition HP BrightView Widescreen Display
Graphics	Integrated Intel Graphics Media Accelerator 4500M
Operating System	Windows Vista
Optical Drive	DVD±RW DL LightScribe
Battery	6-cell Lithium-Ion
Chipset	Intel GL40 Express
Wireless	802.11b/g
Ports	3 x USB 2.0, 1 x HDMI, 1 x VGA, 1 x RJ-45, 1 x Headphone, 1 x Microphone
Card Reader	5-in-1 integrated Digital Media Reader
Webcam	Integrated webcam
Networking	10/100 Ethernet
Weight	2.7 kg (5.95 lbs)
