1-1
D Class System Memory Upgrade
Overview of Memory Installation
The memory installation procedures are organized as follows:
A. Check existing system memory.
B. Turn off power to the system.
C. Remove the front bezel.
D. Remove the side panel.
E. Remove the EMI cover.
F. Remove the Processor/Memory card.
G. Plan the memory configuration.
H. Install memory modules.
I. Replace the Processor/Memory card.
J. Replace the EMI cover.
K. Replace the side panel.
L. Replace the front bezel.
After completing all installation procedures, proceed to the Memory Upgrade
Verification procedure (located after the installation procedures) for instructions on
how to verify correct installation. If the memory verification is not successful, refer
to the section titled Troubleshooting Memory Configuration Error Symptoms at
the end of this manual.
