Rear Panel Components
Figure 1-3 Rear Panel Components
Table 1-2 Rear Panel Components
1 Power Cord Connector 6 VGA Monitor Connector (blue)
2 DisplayPort Monitor Connector 7 PS/2 Mouse Connector (green)
3 PS/2 Keyboard Connector (purple) 8 RJ-45 Network Connector
4 Universal Serial Bus (USB) (6) 9 Line-In Audio Connector (blue)
5 Line-Out Connector for powered audio
devices (green)
NOTE: Arrangement and number of connectors may vary by model.
The Line-in audio connector can be retasked as a microphone connector in the audio driver's control panel.
ENWW Rear Panel Components 3
