HP Designjet Z5200 - PostScript Printer Using

●
Update the printer's firmware
●
Update the paper presets
If you forget the password, see
Cannot access the Embedded Web Server on page 170.
Set the date and time
The printer's date and time settings are mainly useful in job accounting (see Request accounting data
by E-mail on page 104). These settings can be changed using the Embedded Web Server or the
front panel.
●
In the Embedded Web Server, go to the Setup tab and select Date & Time.
●
At the front panel, select the Setup menu icon
, then Front panel options > Date and time
options > Set date or Set time or Set time zone.
Change the sleep mode setting
If the printer is left switched on but unused for a certain period of time, it goes automatically into sleep
mode to save power. To change the time the printer waits before it goes into sleep mode, go to the
front panel and select the Setup menu icon
, then Front panel options > Sleep mode wait time.
Highlight the wait time you want and then press the OK key. You can set the time to 30, 60, 120, 150,
180, 210 or 240 minutes.
Turn the buzzer on and off
To turn the printer's buzzer on or off, go to the front panel and select the Setup menu icon , then
Front panel options > Enable buzzer, highlight on or off and press the OK key. The default buzzer
is set to on.
Change the front-panel display contrast
To change the contrast of the front-panel display, go to the front panel and select the Setup menu
icon
, then Front panel options > Select display contrast, and enter a value using the Up or
Down key. Press the OK key to set the value. The default contrast is set to 50.
Change the units of measurement
To change the units of measurement in the front-panel display, go to the front panel and select the
Setup menu icon
, then Front panel options > Select units, and select English or Metric. By
default the units are set to metric.
22 Chapter 3 Personalizing the printer ENWW
Personal settings

HP Designjet Z5200 - PostScript Printer Specifications

General

Print Technology	Thermal Inkjet
Number of Inks	8
Memory	32 GB (virtual)
Hard Disk	160 GB
Line Accuracy	+/- 0.1%
Maximum Print Resolution	2400 x 1200 dpi
Ink Colors	Cyan, Magenta, Yellow, Light Cyan, Light Magenta, Light Gray
Media Sizes Supported	Up to 44 inches wide
Connectivity	Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0
Minimum Line Width	0.02 mm
Maximum Optical Density (Black)	2.5
Media Types	Bond and coated paper, photographic paper, self-adhesive and banner
Media Sizes Standard (Sheets)	A4, A3, A2, A1, A0
Media Sizes Standard (Rolls)	24 to 44-in rolls
Media Thickness	Up to 0.8 mm
Connectivity, Standard	Gigabit Ethernet (1000Base-T); Hi-Speed USB 2.0 certified; EIO Jetdirect accessory slot
Print Languages	Adobe PostScript 3, Adobe PDF 1.7, TIFF, JPEG, HP-GL/2, HP-RTL, CALS G4
Ink Types	Pigment-based
Operating Temperature Range	5 to 40°C
Dimensions (W x D x H)	1770 x 721 x 1050 mm
