HP DesignJet Z5200 series

8. Carefully lift out the Ink Supply Tubes and close the carriage cover at the same time.
9. Close and lock the Carriage Assembly cover.
10. Carefully feed the Ink Supply Tubes into the print path area.
290 Chapter 6 Removal and Installation ENWW
