HP DesignJet Z5200 series

20. Remove the left Side Plate of the Right Ink Supply Station.
21. Carefully lift the Cartridge Tubes Connector out of the Right Ink Supply Station.
22. Remove two T-10 screws that secure the left Side Plate of the Left Ink Supply Station.
294 Chapter 6 Removal and Installation ENWW
