9. Carefully lift the Electronics Module out of the printer.
NOTE: When you install the Electronics Module make sure it is correctly aligned with the
mounting rail.
NOTE: When you finish installing or replacing this component, you must perform the necessary
Service Calibrations. To find which calibrations you must perform, refer to
Service Calibration Guide to
Removal and Installation on page 170.
Starwheel Assembly
Removal
NOTE: Switch off the printer and remove the power cable.
1. Open the Window.
ENWW Starwheel Assembly 301
