Allen Key #2 Q6675-60041
Cleaning Cloth 9300-2531
Flex Contacts Cleaning Support Q1271-40384
Lubricant Oil Q6675-60061
Media Driver Adjustment Tool Q6675-67009
Handle for Media Driver Tool Support Q6675-67010
Spanner Q6675-67011
Oil Dispenser Q6675-60062
Pinchwheel Alignment Tool Q5669-20595
Pinchwheel Insertion Tool Q5669-20594
Protective Plastic Gloves Q6675-60035
Screwdriver 8710-2456
Tweezers Q6675-60037
Cleaning Assembly C6071-60218
You will also need the following standard hand tools:
Table 6-2 Standard Tool Requirements
Description/Comments Size
Long Torx Screwdriver 1/4 inch drive
Torx Bit (75 mm) 8
10
15
20
Phillips Screwdriver 1
Pliers N/A
Snips N/A
Pipe Spanner 5.5 mm
Flat Bladed Screwdriver N/A
Service Calibration Guide to Removal and Installation
Using the Service Calibration Guide
When you remove most printer components, you will need to perform a particular set of Service
Calibrations and Diagnostic tests to ensure proper printer performance.
The Service Calibration Matrix shows which service calibrations and diagnostic tests need to be
performed whenever you remove and install particular printer components (left most column).
The calibrations must be performed in the order they are shown in the row.
Start by locating the component you have removed and installed in the left most column.
Table 6-1 Toolkit P/N Q6683-67001 (continued)
170 Chapter 6 Removal and Installation ENWW
