HP DesignJet Z5200 series User Manual

NOTE: Even if you do not replace the removed component with a new component, you still need to
perform the calibrations indicated by the matrix.
The Service Calibration Matrix
Service Calibration or Test (Perform in the order shown)
Service Station 8. Service Station test, Drop Detector Calibration
Aerosol Fan
Assembly
8. Service Station test, Drop Detector Calibration
Drop Detector 8. Service Station test, Drop Detector Calibration
Service Station
Spittoon
8. Service Station test, Drop Detector Calibration
Primer Assembly 8. Service Station test, Drop Detector Calibration
Left Ink Supply
Station
7. Ink Delivery System Test (IDS)
Right Ink Supply
Station
7. Ink Delivery System Test (IDS)
Carriage Cover 4. Carriage Assembly, Line Sensor Calibration, 3. Electronics Module
Carriage Latch 4. Carriage Assembly, Line Sensor Calibration, 3. Electronics Module
Carriage PCA 4. Carriage Assembly, Line Sensor Calibration, 3. Electronics Module
PrintMech PCA 3. Electronics Module
Front Panel 3. Electronics Module
Power Supply Unit
(PSU)
3. Electronics Module
Main PCA 3. Electronics Module
Ink Supply Tubes Scan Axis Test, 3. Electronics Module
Media Advance
Drive
2. Paper Drive, Paper Advance Calibration, Electronics Module
Encoder Disk 2. Paper Drive, Paper Advance Calibration, Electronics Module
Encoder Sensor 2. Paper Drive, Paper Advance Calibration, Electronics Module
Media Advance
Roller
2. Paper Drive, Paper Advance Calibration, Electronics Module, Sensors
Carriage Assembly 4. Carriage Assembly, Scan Axis Test, Line Sensor Calibration, 5. Sensors, Cutter Test
Belt Tensioner 4. Carriage Assembly, Scan Axis Test, Line Sensor Calibration, 5. Sensors
Belt Assembly 4. Carriage Assembly, Scan Axis Test, Line Sensor Calibration, 5. Sensors
Scan-Axis Motor 4. Carriage Assembly, Scan Axis Test, Line Sensor Calibration, 5. Sensors
Trailing Cable 4. Carriage Assembly, Scan Axis Test, Line Sensor Calibration, 5. Sensors
Carriage Rear
Bushing
4. Carriage Assembly, Scan Axis Test, Line Sensor Calibration, 5. Sensors, Cutter Test
Line Sensor Line Sensor Calibration, 5. Sensors, Electronics module
Window Position
Sensor
5. Sensors, Electronics module
Out of Paper
Sensor
5. Sensors
ENWW Service Calibration Guide to Removal and Installation 171
