3. Remove the grounding cable attachment screw from the PrintMech PCA.
4. Remove the three T-15 screws that secure the PrintMech PCA to the Service Station.
5. Remove the PrintMech PCA from the printer.
NOTE: When you finish installing or replacing this component, you must perform the necessary
Service Calibrations. To find which calibrations you must perform, refer to
Service Calibration Guide to
Removal and Installation on page 170.
Pen to Paper Space (PPS) Solenoid
Removal
NOTE: Switch off the printer and remove the power cable.
1. Remove the Right Cover (refer Right Cover on page 185).
ENWW Pen to Paper Space (PPS) Solenoid 221
