5. Remove the Pen to Paper Space (PPS) Solenoid from the printer.
NOTE: When you finish installing or replacing this component, you must perform the necessary
Service Calibrations. To find which calibrations you must perform, refer to
Service Calibration Guide to
Removal and Installation on page 170.
Spindle
Removal
NOTE: Switch off the printer and remove the power cable.
1. Pull the left end of the Spindle (viewed from the front of the printer) out of the Left Spindle Holder.
2. Lift the Spindle out of the printer towards the left (viewed from the front of the printer).
ENWW Spindle 223
