HP DesignJet Z5200 series

21. Remove the four T-15 screws that secure the Ink Supply Tubes to the Carriage Assembly.
22. Carefully lift out the Ink Supply Tubes and close the carriage cover at the same time.
23. Close and lock the Carriage Cover.
248 Chapter 6 Removal and Installation ENWW
