466 Chapter 10 Repacking instructions
Repacking
•
End Caps & POREX supplements, Carton boxes & Pallet
•
Plastic Bag
•
Adhesive tape (reinforced type)
•
Ink tube retainer carton pad
•
Carriage retainer foam
•
Primer retainer foam
•
Spindle retainer carton pad
•
Others (zip plastic bags, adhesive tape, etc.)
See the following picture to identify the special packaging elements to secure printer components:
Step 1: Removing the consumables from the printer
The first step before proceeding to re-pack the unit is to remove the media, ink consumables (print-heads
& ink cartridges) & print-head cleaner from the printer.
•
With the unit switched ON, request a print-head replacement trough the Front Panel menu.
•
Once the carriage is on the platen area, switch OFF the printer trough the rear power switch.
•
Open the window, open the carriage latch & proceed to remove all the print-heads.
Printhead re-packaging instructions are also provided
