3. Remove one T-20 screw that secures the Left Cover.
4. Remove one T-15 screw and one T-20 screw that secure the Left Cover.
5. Remove the Left Cover from the printer.
Left Trim
Removal
WARNING! Switch off the printer and remove the power cable.
1. Remove the Output Platen See Output Platen on page 361.
