4. Open the Rear Door slightly (as shown, approximately 30 degrees).
5. Lift the left side of the rear door sufficiently to release it from the three location studs.
6. Remove the Rear Door from the printer.
Right Connector Cover
Removal
WARNING! Switch off the printer and remove the power cable.
1. For the 42-inch model, remove the Rear Door See Rear Door (42-inch) on page 235.
238 Chapter 8 Removal and installation ENWW
