17. Remove five T-15 screws (Type G) that secure the Ink Supply Tubes to the Carriage Assembly.
18. Remove the Ink Supply Tubes from the Carriage Assembly and safely place to one side of the
printer.
19. Remove one T-20 screw that attaches the bonding cable to the printer chassis.
