WARNING! Switch off the printer and remove the power cable.
1. Remove the Right Cover See Right Cover on page 216.
2. Remove the Left Cover
See Left Cover on page 222.
3. Remove the Top Cover
See Top Cover (60-inch) on page 229.
4. Remove the Service Station
See Service Station on page 252.
5. For the 42-inch model, remove the Rear Door
See Rear Door (42-inch) on page 235.
6. Squeeze the corners of the OMAS Access Cover release it from the bottom of the printer.
7. Remove the OMAS Access Cover from the printer.
ENWW
Disassembly order
363
Removal and
installation
