HP DL380P User Manual

Component identification 18
Item LED Status Definition
Flashing blue The drive carrier firmware is being updated or requires an update.
2
Activity ring Rotating green Drive activity
Off No drive activity
3
Do not remove Solid white Do not remove the drive. Removing the drive causes one or more of
the logical drives to fail.
Off Removing the drive does not cause a logical drive to fail.
4
Drive status Solid green The drive is a member of one or more logical drives.
Flashing green
The drive is rebuilding or performing a RAID migration, stripe size
migration, capacity expansion, or logical drive extension, or is
erasing.
Flashing
amber/green
The drive is a member of one or more logical drives and predicts
the drive will fail.
Flashing amber The drive is not configured and predicts the drive will fail.
Solid amber The drive has failed.
Off The drive is not configured by a RAID controller.
PCI riser cage LED
CAUTION: To prevent damage to the server or expansion boards, power down the server and
remove all AC power cords before removing or installing the PCI riser cage.
Status
On = AC power is connected.
Off = AC power is disconnected.
Missing = Riser cage is not installed, or power might not be
connected.
Storage Networks
www.storagenetworks.com
Authorized HP Reseller
Spare Parts:
http://www.storagenetworks.com/products/servers/hp/DL380G8/dl380pg8_servers_landing.php

HP DL380P Specifications

General

Product Line	ProLiant
Rack Height	2U
Processor Sockets	2
Memory	Up to 768 GB
RAID Levels	0, 1, 5, 6, 10, 50, 60
Management	HP iLO (Integrated Lights-Out)
Server Type	Rack
Processor	Intel Xeon E5-2600 series
Chipset	Intel C600
Memory Slots	24
Memory Type	DDR3
Drive Bays	25 SFF
Hard Drive Interface	SAS, SATA
Network	Gigabit Ethernet
Power Supply	Redundant Power Supplies supported
Expansion Slots	6 PCIe Gen3 slots
Operating System Support	Windows Server, Linux, VMware
Remote Management	HP iLO (Integrated Lights-Out)
Form Factor	Rackmount
