2. Push the button to remove the stand-base assy.

3. Remove the screws to remove the Rear cover.

4. Remove the tapes and disconnect the connectors

5. Remove the screws to remove the WEBCAM MODULE

6. Remove the AUDIO /USB /KEY BOARD

7. Remove the screws to remove the Latch

8. Remove the tapes and Disconnect the pins and remove the speakers

9. Remove the screws on mid-frame

10. Remove the mylar on PCBA Board. Remove the main board and power board

11. Remove the connectors and Remove the screw to remove the Connector Board

12. Remove the screws to remove the Webcam holder_B other

13. Remove the Webcam Module.

3.2 Location of components requiring selective treatment. The photos and/or graphics below identify the location of the parts or

components requiring selective treatment within the main unit. For End-of-Life product disassembly instructions of external

accessories including external power supply (EPS), external keyboard (KB) external mouse and external cables and cords, refer to the

following URL:

End-

of-Life Product Disassembly Instructions (hp.com)

1. Precaution

Please read the precautions as follows to prevent any damages to the LCD Monitor.

Make sure all power connection is removed. Be sure that the LCD Monitor is in power off status.

Prepare soft cloth and sponge as

working platform to place LCD

monitor horizontally.

Other manuals for HP E24mv
