QuickSpecs

HP Elite x2 1012 G1

Technical Specifications

Not all configuration components are available in all regions/countries.

c04895999 — DA – 15477 — Worldwide — Version 16 – March 22, 2017

Page 23

WSE Supported USB Ports

Single USB 2.0/3.0 Root Port

USB Hub

Supports direct connection to an external

USB Hub device. Any USB devices on the

Dock device should be connected to the

external USB Hub.

Port Powering

Module does not support USB device

powering. Any Dock device must be self-

powered or powered from an external

USB Hub in the Dock Device. The module

is capable of managing the powering

requirements of USB devices connected to

the Dock USB Hub external to the module.

WSE Supported Devices

USB devices listed in ‘Supported USB

Peripherals over USB’ below are

supported, separately and

simultaneously. It supports control,

interrupt, bulk and isochronous flows

based on the supported device

capabilities.

Number of USB devices

supported on Dock device

At least 12 USB devices

Number of USB Hub Tiers

supported

Maximum number of Hub Tiers connected

to the external Hub in the Dock device is

3. A 4

Tier will only support non Hub

devices.

Supported USB peripherals

over WSE

Device Class

Comment

HID

Supported

Printer

Supported

Communication

Device Class (CDC)

Supported

Mass Storage Class

(MSC)

Supported

Hub

Supported

Audio Class

Supported

USB Video Class

(UVC)

Supported

* Wireless access point and Iternet service required. Availability if public wireless access points limited.

The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final

specifications differ from the draft specifications, it may affect the ability of the notebook to

communicate with other 802.11ac WLAN devices.

Intel® Dual Band Wireless-AC 8260 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo*

Wireless LAN

Standards

IEEE 802.11a

IEEE 802.11b

IEEE 802.11g

IEEE 802.11n

IEEE 802.11ac

Interoperability

Wi-Fi certified

Frequency Band

802.11b/g/n

 2.402 – 2.482 GHz

Note:

The FCC has declared as of January 1,

2015 products that utilize passive

Other manuals for HP ELITE x2 1012 G1

User Guide76 pages

Maintenance And Service Guide96 pages

Questions and Answers:

Need help?

Do you have a question about the HP ELITE x2 1012 G1 and is the answer not in the manual?

HP ELITE x2 1012 G1 Specifications

General

Bus type	OPI
Stepping	D1
Tjunction	100 °C
Processor code	SR2EN
Processor cache	4 MB
Processor cores	2
Processor family	Intel® Core™ m3
Processor series	Intel Core m3-6Y series
Processor socket	BGA 1515
Processor threads	4
Processor codename	Skylake
Processor frequency	0.9 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	20 X 16.5 mm
Conflict-Free processor	Yes
PCI Express slots version	3.0
Processor boost frequency	2.2 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
Graphics & IMC lithography	14 nm
PCI Express configurations	1x2+2x1, 2x2, 1x4, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	4.5 W
Maximum number of PCI Express lanes	10
Device type	Tablet PC
Form factor	Slate
Product color	Silver
Internal memory	4 GB
Memory clock speed	1866 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	180 GB
Display diagonal	12 \
Touch technology	Multi-touch
Display resolution	1920 x 1280 pixels
Graphics card	HD Graphics 515
On-board graphics card ID	0x191E
On-board graphics card model	Intel® HD Graphics 515
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	850 MHz
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Country of origin	China
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Battery capacity	2800 mAh
Battery life (max)	10 h
AC adapter power	45 W
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Sustainability certificates	ENERGY STAR
Platform	Windows
Operating system architecture	64-bit
Processor ARK ID	88198
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
