HP EliteBook 820 G1 User Manual

Solid-state drive
Description Spare part number
For use only on computer models equipped with an AMD processor:
256-GB, SATA-3, SED, Opal 2, solid-state drive 765614-001
256-GB, SATA-3, SED, Opal 1, solid-state drive 765613-001
240-GB, SATA-3, solid-state drive 765612-001
180-GB, SATA-3, SED, Opal 1, solid-state drive 765611-001
180-GB, SATA-3, solid-state drive 765610-001
128-GB, SATA-3, solid-state drive 765609-001
For use only on computer models equipped with an Intel processor:
512-GB, SATA-3, solid-state drive 752103-001
256-GB, SATA-3, SED, Opal 2, solid-state drive 761906-001
256-GB, SATA-3, SATA-3, Opal 2, locked, solid-state drive 777832-001
256-GB, SATA-3, SED solid-state drive 730567-001
240-GB, SATA-3, solid-state drive 730566-001
180-GB, SATA-3, SED, Opal 1, solid-state drive 775247-001
180-GB, SATA-3, solid-state drive 730565-001
128-GB, SATA-3, locked, Opal 2, solid-state drive 764507-001
128-GB, SATA-3, locked, solid-state drive 766679-001
128-GB, SATA-3, solid-state drive 744716-001
120-GB, mSATA-3, SED solid-state drive 730568-001
32-GB, SATA-3, solid-state drive 743008-001
Before removing the solid-state drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the service cover (see
Service cover on page 71).
5. Remove the battery (see
Battery on page 73).
Remove the solid-state drive:
1. Remove the Phillips PM2.0×2.5 screw (1) that secures the solid-state drive to the system board.
(The solid-state drive tilts up.)
80 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts ENWW

HP EliteBook 820 G1 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Country of origin	China
Bus type	DMI2
Stepping	D0
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-4600U
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4600 Mobile series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Haswell
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.3 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	4x1, 2x4
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	12
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Card reader integrated	Yes
Total storage capacity	500 GB
Number of HDDs installed	1
Number of SSDs installed	0
Display surface	Matt
Display diagonal	12.5 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0xA16
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4400
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.3
On-board graphics card base frequency	200 MHz
On-board graphics card DirectX version	11.2/12
On-board graphics card dynamic frequency (max)	1100 MHz
Intel segment tagging	Enterprise
Audio system	DTS Studio Sound
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	Touchpad
Recovery operating system	Windows 8 Pro
Operating system installed	Windows 7 Professional
Processor code	SR1EA
Processor ARK ID	76616
Intel TSX-NI version	0.00
Processor package size	40 x 24 x 1.5 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Smart Connect Technology version	1.00
Battery capacity	46 Wh
Battery life (max)	11.25 h
AC adapter power	45 W

Weight and Dimensions

Depth	215 mm
Width	310 mm
Height	21 mm
Weight	1330 g
