Display assembly
Description Spare part number
Display panel assembly, touch screen 821657-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 32).
5. Remove the battery (see Battery on page 35).
Remove the display assembly:
1. Position the computer upside down.
2. Disconnect the display cable from the system board.
Component replacement procedures 61
