Display assembly
NOTE: HP EliteBook 840 models offer both touch and non-touch displays. Non-touch displays are spared at
the subcomponent level only. Touch displays are only spared as a whole (touch display components are not
spared).
In non-touch models, you can remove the raw display panel with the display assembly still connected to the
computer. For more information, see
Display panel (non-touch) on page 69.
The following section shows how to remove the raw display panel without removing the display assembly
from the computer. See the display section later in this chapter to remove internal components that require
that you remove the display assembly.
Description Spare part number
Display assembly, touch screen (whole assembly)
Display assembly, 14-inch, HD+, for use in HP EliteBook 740/840 models 737735-001
Display assembly, 14-inch, HD+, for use in HP ZBook 14 models 739848-001
Display assembly, 15-inch, HD, for use in HP EliteBook 750/850 models 766680-001
Display enclosure (non-touch models) (includes 4 transceivers with antennas)
Display bezel for use in HP EliteBook 740/840 models 730949-001
Display bezel for use in HP ZBook 14 models 730948-001
Display bezel for use in HP EliteBook 850 models 730811-001
Before removing the display assembly, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the following components:
a. Service cover (see
Service cover on page 51)
b. Battery (see
Battery on page 53)
c. Fan (see
Fan on page 79)
d. Keyboard (see
Keyboard on page 65)
e. Base enclosure (see
Base enclosure on page 73)
Remove the display assembly:
1. Disconnect the display panel cable (1) from the system board.
98 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
