Reverse this procedure to install the card reader board.
VGA/USB board
Description Spare part number
VGA/USB board for use in HP EliteBook 740/840/HP ZBook 14 models 730966-001
VGA/USB board for use in HP EliteBook 750/850 models 730820-001
Before removing the VGA/USB board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the following components:
a. Service cover (see
Service cover on page 51)
b. Battery (see
Battery on page 53)
c. Fan (see
Fan on page 79)
d. Keyboard (see
Keyboard on page 65)
e. Base enclosure (see
Base enclosure on page 73)
Remove the VGA/USB board:
1. Disconnect the cable from the VGA/USB board (1).
2. Remove the two Phillips PM2.0×5.0 screws (2) that secure the VGA/USB board to the top cover.
Component replacement procedures 81
