HP EliteBook 8440P User Manual

Audio
Your computer enables you to use a variety of audio features:
●
Play music using your computer speakers and/or connected external speakers
●
Record sound using the internal microphones or connect an external microphone
●
Download music from the Internet
●
Create multimedia presentations using audio and images
●
Transmit sound and images with instant messaging programs
●
Stream radio programs (select models only) or receive FM radio signals
●
Create or “burn” audio CDs (select models only)
Connecting external audio devices
WARNING! To reduce the risk of personal injury, adjust the volume before putting on headphones,
earbuds, or a headset. For additional safety information, refer to the Regulatory, Safety and
Environmental Notices.
To connect external devices such as external speakers, headphone, or a microphone, refer to the
information provided with the device. For best results, remember the following tips:
●
Be sure that the device cable is securely connected to the correct jack on your computer. (Cable
connectors are normally color-coded to match the corresponding jacks on the computer.)
●
Be sure to install any drivers required by the external device.
NOTE: A driver is a required program that acts like a translator between the device and the
programs that use the device.
Checking your audio functions
To check the system sound on your computer, follow these steps:
1. Select Start > Control Panel.
2. Click Hardware and Sound.
3. Click Sound.
4. When the Sound window opens, click the Sounds tab. Under Program Events, select any sound
event, such as a beep or alarm, and click the Test button.
You should hear sound through the speakers or through connected headphones.
To check the record functions of the computer, follow these steps:
1. Select Start > All Programs > Accessories > Sound Recorder.
2. Click Start Recording and speak into the microphone. Save the file to the desktop.
3. Open Windows Media Player and play back the sound.
42 Chapter 4 Multimedia

HP EliteBook 8440P Specifications

General

HDD speed	7200 RPM
HDD interface	SATA II
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-620M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-600 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.66 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	3.33 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® QM57 Express
Display diagonal	14 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Discrete graphics card model	NVIDIA Quadro HD 6310
Maximum graphics card memory	- GB
On-board graphics card model	Intel® HD Graphics
Discrete graphics card memory	0.512 GB
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Type	PC
Graphics card family	NVIDIA
Intel segment tagging	Enterprise
Audio system	HP Premier Sound
Bluetooth version	2.1+EDR
Networking features	Gigabit Ethernet
Mobile network generation	3G
Operating system installed	Windows 7 Professional
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	-
USB 2.0 ports quantity	3
CardBus PCMCIA slots quantity	0
Cable lock slot type	Kensington
Product color	Silver
Country of origin	China
Keyboard layout	QWERTY
Pointing device	Touchpad
Processor code	SLBPE
Processor ARK ID	43560
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	236 mm
Width	336 mm
Weight	2120 g
Height (front)	31 mm
