HP EliteBook 8760w Service Manual

Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not
place the computer directly on your lap or obstruct the computer air vents. Use the computer only on
a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft
surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to
contact the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer
and the AC adapter comply with the user-accessible surface temperature limits defined by the
International Standard for Safety of Information Technology Equipment (IEC 60950).
iii

HP EliteBook 8760w Specifications

General

Bus type	DMI
Stepping	D2
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-2630QM
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-2600 Mobile Series
Processor socket	Socket 988
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM67 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Display diagonal	17.3 \
Native aspect ratio	16:9
Power supply type	AC/DC
Graphics card family	AMD
Intel segment tagging	Enterprise
Operating temperature (T-T)	41 - 95 °F
Compliance industry standards	IEEE802.3, IEEE802.3u, IEEE802.3ab
Memory slots	4x SO-DIMM
Internal memory	8 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Pointing device	Touchpad + Pointing Stick
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	2
CardBus PCMCIA slots quantity	0
AC adapter power	200 W
Battery capacity	83 Wh
Sustainability certificates	ENERGY STAR
Product color	Silver
Country of origin	China
On-board graphics card ID	0x116
Discrete graphics card model	AMD FirePro M5950
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Processor code	SR02Y
Processor ARK ID	52219
Processor package size	37.5 x 37.5 (rPGA998) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	272.7 mm
Width	416.5 mm
Height	37.4 mm
Weight	3470 g
