Speaker assembly
Description Spare part number
Speaker assembly contains four speakers, with foam/rubber tape 937416-001
Before removing the speaker assembly, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the computer
on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 26).
5. Remove the battery (see Battery on page 27).
Remove the speaker assembly:
1. Disconnect the front speakers from the system board (1).
2. Remove the four screws securing the front speakers (2).
3. Remove the plastic tape holding the front speaker cable (3).
4. Remove the front speakers (4).
5. Remove the rear speaker (5).
Component replacement procedures 29
