(12): Front speakers
2. Remove the ve Phillips screws that secure the system board to the computer.
3. Lift the right side of the system board up at an angle (1).
CAUTION: To avoid damaging or breaking the system board, use two hands when removing the board. Do
not lift up on the narrow end of the board.
4. Pull the at ribbon cable through the slit in the system board (2).
Component replacement procedures 33
