Rear panel components (ProDesk 400)
1 DisplayPort Monitor Connector 4 USB 2.0 Ports (black)
2
VGA Monitor Connector 5 RJ-45 Network Connector
3
USB 2.0 Ports with enhanced power (black) 6 Power Cord Connector
NOTE: The two upper USB ports have additional power capacity to support the Desktop Mini External Expansion Sleeves.
NOTE: The two lower USB ports support wake-from-sleep states if that option is enabled in the Computer Setup (F10)
utility.
Rear panel components (ProDesk 400) 7
