EL-MF877-00 Page 6
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Figure19 Loose the stone card screws Figure20 Remove the stone card from MB
Figure21 Loose the screws from board Figure22 Remove M/B from chassis
Figure23 Loose the screws from system fan Figure24 Remove system fan
