Installing a 2.5-inch hard drive
1. Remove/disengage any security devices that prohibit opening the computer.
2. Remove all removable media, such as compact discs or USB ash drives, from the computer.
3. Turn o the computer properly through the operating system, and turn o any external devices.
4. Disconnect the power cord from the AC outlet and disconnect any external devices.
IMPORTANT: Regardless of the power-on state, voltage is always present on the system board as long
as the system is plugged into an active AC outlet. To prevent damage to internal components, you must
disconnect the power cord from the power source before opening the computer.
5. Remove the computer access panel.
6. Install four black-and-blue M3 mounting screws (two on each side of the drive).
NOTE: M3 metric mounting screws can be purchased from HP.
When replacing a drive, transfer the four mounting screws from the old drive to the new drive.
Removing and installing drives 39
