HP EliteDesk 800 G3 TWR Hardware Reference Guide

Replacing the front bezel
Insert the three hooks on the bottom of the bezel into the rectangular holes on the chassis (1), and then
rotate the top of the bezel onto the chassis (2) and snap it into place.
Removing and installing the optional front bezel dust lter
Some models are equipped with an optional front bezel dust lter. You must periodically clean the dust lter
so that the dust collected on the lter does not impede air ow through the computer.
NOTE: The optional front bezel dust lter is available from HP.
To remove, clean, and replace the dust lter:
1. Turn o the computer properly through the operating system, and turn o any external devices.
2. Disconnect the power cord from the AC outlet and disconnect any external devices.
NOTE: Regardless of the power-on state, voltage is always present on the system board as long as the
system is plugged into an active AC outlet. To prevent damage to internal components, you must
disconnect the power cord from the power source before opening the computer.
10 Chapter 2 Hardware upgrades

HP EliteDesk 800 G3 TWR Specifications

General

Form Factor	Tower
Processor Options	Intel Pentium, Intel Celeron
Memory	Up to 64 GB DDR4-2400 SDRAM
Storage Options	2.5" HDD/SSD, M.2 SSD
Graphics	Intel HD Graphics 630
Operating System	Windows 10 Pro
Audio	Realtek HD ALC221-VB Audio
Expansion Slots	1 PCIe x16
Ports (Front)	2 x USB 3.1 Gen 1, 2 x USB 2.0, 1 x headphone/microphone combo
Ports (Rear)	4 x USB 3.1 Gen 1, 4 x USB 2.0, 1 x VGA, 1 x DisplayPort, 1 x RJ-45, 1 x audio line-out, 1 x audio line-in
Power Supply	250W, up to 92% efficient PSU
Optical Drive	Optional DVD-Writer
Chipset	Intel® Q270
