HP EliteDisplay E240 User Manual

Downloading from the Web
If you do not have a computer or source device with an optical drive, you can download the latest version
of .INF and .ICM files from the HP monitors support Web site.
1. Go to
http://www.hp.com/support and select the appropriate country and language.
2. Select Drivers & Downloads, type your monitor model in the Find my product search field, and click Go.
3. If necessary, select your monitor from the list.
4. Select your operating system, and then click Next.
5. Click Driver - Display/Monitor to open the list of drivers.
6. Click on the driver.
7. Click the System Requirements tab, and then verify that your system meets the program minimum
requirements.
8. Click Download and follow the on-screen instructions to download the software.
16 Chapter 2 Using the monitor

HP EliteDisplay E240 Specifications

General

3D	No
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	23.8 \
Display technology	LED
Viewable size, vertical	296.46 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	527.04 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1400 x 900, 1600 x 900, 1680 x 1050 (WSXGA+)
On/off switch	Yes
USB hub version	2.0
USB Type-A downstream ports quantity	3
Product color	Black
Country of origin	China
Market positioning	Business
Pivot angle	0 - 90 °
Tilt angle range	-5 - 25 °
Panel mounting interface	100 x 100 mm
Sustainability certificates	ENERGY STAR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	35 W
Power consumption (off)	0.12 W
Annual energy consumption	31 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W

Weight and Dimensions

Depth (without stand)	49.5 mm
Width (without stand)	557.2 mm
Height (without stand)	342.2 mm
Weight (without stand)	3800 g
